Clear cell (tubulo)papillary renal cell carcinoma

2021-10-29   Michelle S. Hirsch , Paola Dal Cin

1.Department of Pathology, Brigham and Women's Hospital & Harvard Medical School, Boston, MA 02115, USA
2.Brigham and Women's Hospital , Harvard Medical School, Boston , MA (USA)



Clear cell (tubulo)papillary renal cell carcinoma (CCTPRCC) is a recently-recognized tumour that shares morphologic features with both clear cell renal cell carcinoma (CCRCC) and papillary renal cell carcinoma (PRCC) but behaves in a more indolent fashion.

Clinics and Pathology


4% of renal cell carcinoma, historically most often mistaken for CCRCC. First described in the setting of end stage renal disease, but now known to be most frequently recognized and encountered in a sporadic setting

Clinical features

Patients are usually asymptomatic as these tumors are often small and incidentally found.

Macroscopic apperances

Well-defined and well encapsulated small tumor with frequent cystic formation; usually solitary and unilateral, but multifocality and bilaterally have been reported.1-3


Characteristic histology includes: branched tubular structures, straight nuclear alignment (picket fence nuclei) above the basement membrane, variable papillary structures protruding into cystic spaces, and low nuclear grade (Fig.1A); an associated fibrous capsule and/or fibromuscular stroma may be present in a subset of cases


Strong, diffuse positivity for cytokeratin (CK) 7, and absence of racemase (AMACR) and a cup-like staining pattern for carbonic anhydrase (CA) IX, which has been thought to be unique to this entity (Fig.1B)

Fig 1 : Clear cell tubulopapillary renal cell carcinoma (CCTPRCC) is a low grade neoplasm characterized by tubulopapillary architecture (a predominant tubular architecture is shown in the left image), a ‘picket fence-like’ arrangement of the nuclei, and clear cytoplasm (A). Carbonic anhydrase IX (CA9) expression (right) shows a characteristic ‘cup-like’ staining pattern (B).



• Combine FISH data, NGS data and virtual karyotyping by SNP array demonstrated minimal genetic variability in this tumor, with normal status of VHL gene (methylation, LOH 3p, mutations) .5-8

• Some somatic mutaciones, as MET, PTEN, ERBB4, and STK11, have been identified , and RNA profiling revealed overexpression of miR-200 family, distinct from those in other renal tumors 2


Prognosis and treatment

Indolent tumor with good clinical outcomes, without any recurrences, metastases, or lymph node involvement .4


Reference NumberPubmed IDLast YearTitleAuthors
1255507672014Clear cell papillary renal cell carcinoma: a review.Kuroda N et al
2306723342019Clear Cell Papillary Renal Cell Carcinoma.Zhao J et al
3290627162018Clear cell tubopapillary renal cell carcinoma mimicking polycystic kidney disease: A case report.Gomez G et al
4273647052016What is the malignant potential of clear cell papillary renal cell carcinoma?Williamson SR et al
5242943812013Clear cell papillary renal cell carcinoma: a clinicopathological study emphasizing ultrastructural features and cytogenetic heterogeneity.Shi SS et al
6268976412016Clear cell papillary renal cell carcinoma, renal angiomyoadenomatous tumor, and renal cell carcinoma with leiomyomatous stroma relationship of 3 types of renal tumors: a review.Hes O et al
7311759172019Clear cell papillary renal cell carcinoma: molecular profile and virtual karyotype.Morlote DM et al
8321022502020Similarities and Differences between Clear Cell Tubulo-Papillary and Conventional Clear Cell Renal Cell Carcinoma: A Comparative Phenotypical and Mutational Analysis.Giunchi F et al
